Manhattan
4K@60Hz DisplayPort Monitor Cable
4K@60Hz DisplayPort Monitor Cable
DisplayPort Male / DisplayPort Male, 1 m (3.3 ft.), Black
SKU: 306935
Highlights
- DisplayPort 20-pin male to DisplayPort 20-pin male latching connections
- Delivers high-bandwidth, digital audio/visual signals from PC to display and other DisplayPort-enabled devices — up to 4K@60Hz resolution
- Fully shielded to reduce EMI and other interference sources

[ view high resolution images ]
High-definition performance for personal computing
Manhattan DisplayPort Cables provide a single-cable solution that delivers both high-definition digital audio and video signals between desktop and notebook computers and an output device. With 21.6 Gbps bandwidth (HBR2), DeepColor and 24-bit, 8-channel uncompressed audio capability, the 20-pin connector is small, compact and ideal for use with DisplayPort-equipped computers, flat-panel displays, slim-profile devices and many consumer electronics including Blu-ray players and game consoles. Full foil and braided shielding, molded boots with strain relief, protective PVC jackets and gold-plated connections help Manhattan DisplayPort Cables provide maximum conductivity and clear, crisp signal transmissions with reduced EMI interference and distortion.
- DisplayPort 20-pin male to DisplayPort 20-pin male latching connections
- Delivers high-bandwidth, digital audio/visual signals from PC to display and other DisplayPort-enabled devices — up to 4K@60Hz resolution
- Fully shielded to reduce EMI and other interference sources
- Plug and play for box-to-box applications
- Molded PVC boot
- Lifetime Warranty
- Standards and Certifications
- UL 20276
- DisplayPort v1.2
Connectors - DisplayPort 20-pin male with latches (2)
- Nickel plated
- Molded PVC boot
Cable - 28 AWG connectors
- Shielding: aluminum and Mylar braid
- Withstanding voltage: 300 VDC
- Insulation resistance: 5 MΩ
- Contact resistance: 10 Ω
- PVC jacket
Package Contents - 4K@60Hz DisplayPort Monitor Cable
Additional SKUs
- EAN: 0766623306935
- UPC: 766623306935
Physical Specifications
- Product net weight: 0.17 lbs
- Product gross weight: 0.2 kg
- Dimensions: 3.3 ft.
