DisplayPort 1.2a to DVI-D Adapter
DisplayPort 1.2a to DVI-D Adapter
DisplayPort 1.2a Male to DVI-D Female, Active, 23 cm (9 in.), Black
Highlights
- Actively converts a DisplayPort signal to a DVI-D dual-link signal
- Delivers a high-quality digital video signal – ideal for using a new DisplayPort source with an existing DVI-D display
- Supports Deep Color, high-bandwidth 10.8 Gbps applications and resolutions up to 2560x1600@60Hz
[ view high resolution images ]
Easily connect a DisplayPort source to an DVI-D display
The Manhattan DisplayPort Adapter helps establish a fast, simple and convenient link between newer DisplayPort-equipped sources and existing DVI-D displays. The Manhattan DisplayPort Adapter is easy and quick to install. No complicated configuration or setup is required, which helps fully realize the investment, value and service life of DVI-D displays. Its all-in-one design is a compact, integrated solution that eliminates unnecessary cables, tangles and clutter to keep installations and workspaces neat and orderly.
- Actively converts a DisplayPort signal to a DVI-D dual-link signal
- Delivers a high-quality digital video signal – ideal for using a new DisplayPort source with an existing DVI-D display
- Supports Deep Color, high-bandwidth 10.8 Gbps applications and resolutions up to 2560x1600@60Hz
- Integrated cable design relieves port pressure; built-in screw holes secure cable connection
- Compatible with surround and multidisplay modes, nVidia® and AMD® Eyefinity, and with D++ (dual mode graphics cards)
- Three-Year Warranty
- Standards and certifications
- Displayport 1.2a
- HDCP
General - 8-bit and 10-bit Deep Color support
- 10.8 Gbps bandwidth
- Auxiliary channel support, 1 Mbps
- One-lane, one-direction, four-line connection support
- Active
Connectors - DisplayPort 20-pin male
- DVI-D 24+1-pin female
- Gold-plated contacts
- ABS boots, built-in PVC strain relief
Physical - Length: 23 x 4 x 1.5 cm (9 x 1.7 x 0.6 in.)
- Weight: 4 g (0.9 oz.)
Operating Environment - Operation Temperature: 0 - 50°C (32 - 122°F)
- Storage Temperature: -10 - 80°C (14 - 176°F)
- Humidity (noncondensing): 0 - 96%
Package contents - DisplayPort 1.2a to DVI-D Adapter
Additional SKUs
- EAN: 0766623152228
- UPC: 766623152228
Physical Specifications
- Product net weight: 0.09 lbs
- Product gross weight: 0.09 kg
- Dimensions: 9.06 (L) x 1.65 (W) x 0.59 (H) [in]
- Datasheet
- Datasheet » Download
