USB 3.0 to Gigabit Network Adapter
USB 3.0 to Gigabit Network Adapter
10/100/1000 Mbps Gigabit Ethernet, SuperSpeed USB
Highlights
- Adds a high-speed Gigabit network connection for notebooks, 2-in-1s, Ultrabooks™, Surface® devices, MacBook® and Chromebook™
- One Gigabit Ethernet port (RJ45) supports up to 2 Gbps full-duplex transfer speed
- Upgrade your notebook or desktop computer to full gigabit speeds
[ view high resolution images ]
The Manhattan USB 3.0 to Gigabit Network Adapter is a compact, high-performance network adapter that allows you to upgrade your desktop or notebook computer to operate at 10/100/1000 Mbps speeds on the LAN. Because it attaches to one of your computer’s USB connectors, there is no need to open up your PC — and the user-friendly setup software makes installation quick and easy.
Fast and Frugal
The Manhattan USB 3.0 to Gigabit Ethernet Network Adapter is equipped with a fully auto-sensing Gigabit LAN port capable of delivering a peak performance of 2 Gbps in full-duplex mode. It delivers exceptional performance for everyone who requires an ultra-fast and solid network connection. The latest in power-saving technology ensures the hub does not drain the battery of your computer in the process.
Auto-Negotiation
The USB 3.0 Gigabit Adapter will automatically detect the network speed that the LAN switch port is set to and run at the same speed. The adapter supports 10Base-T Ethernet, 100Base-TX and 1000Base-T Gigabit Ethernet.
Full Duplex
When running in full duplex mode, the USB 3.0 Gigabit Adapter connects at the following link speeds: 20 Mbps (10Base-T Ethernet), 200 Mbps (100Base-TX Fast Ethernet) and 2 Gbps (1000Base-T Gigabit Ethernet).
Portable Design
The Manhattan USB 3.0 to Gigabit Network Adapter is compact and can be easily used from one computer to another or transferred in your notebook case as you travel. It doesn’t take up a lot of space or add clutter to your work area.
Compatible with Just About Everything
From Windows®-based Ultrabooks (like the Dell™ XPS or Acer® Aspire series) to Chromebooks™, and Apple Macbooks® to laptops and desktop PCs, as long as your device features a standard USB 2.0 or USB 3.0 port (USB 3.0 recommended for best performance), you are good to go.
- Adds a high-speed Gigabit network connection for notebooks, 2-in-1s, Ultrabooks™, Surface® devices, MacBook® and Chromebook™
- One Gigabit Ethernet port (RJ45) supports up to 2 Gbps full-duplex transfer speed
- Upgrade your notebook or desktop computer to full gigabit speeds
- Energy-saving Energy Efficient Ethernet (IEEE 802.3az) technology
- Works with Ultrabooks, laptops and PCs running Windows Windows 7 or Windows 8, Windows 8.1 or Windows 10/11
- Compatible with macOS® 10 and 11 Big Sur
- Provides legacy support for devices running Windows XP® and Vista®
- One 1000Base-T RJ45 Gigabit Ethernet port with Auto MDI-X (auto uplink) support
- Supports jumbo frames up to 4 kBytes
- Wake-On-LAN (WOL) support
- Supports Preboot Execution Environment (PXE)
- Compliant with the USB 3.0 specification and backward compatible to USB 2.0 and USB 1.1 devices
- Three-Year Warranty
- Standards
- USB Specification version 3.2 Gen 1
- USB Specification version 2.0
- USB Specification version 1.1
- USB Specification version 1.0
- IEEE 802.1p (Traffic Prioritization)
- IEEE 802.1q (VLAN Tagging)
- IEEE 802.3 (10Base-T Ethernet)
- IEEE 802.3ab (Twisted Pair Gigabit Ethernet)
- IEEE 802.3az (Energy Efficient Ethernet EEE)
- IEEE 802.3u (100Base-TX Fast Ethernet)
General - USB Type-A connector
- RJ45 connector
- Certifications: FCC Class B, CE, RoHS
Power - USB bus-powered
- Operating mode: 420 mA
- Suspend mode : 38 mA
Environmental - Dimensions: 59 (L) x 22 (W) x 16 (H) mm (2.32 x 0.87 x 0.63 in.)
- Cable length: 15 cm (6 in.)
- Weight: 145 g (5.11 oz.)
- Operating temperature: 0 – 40°C (32 – 104°F)
- Storage temperature: -10 – 80°C (14 – 176°F)
- Storage humidity: 5 – 85%, non-condensing
Supported Operating Systems - Windows XP, Windows Vista, Windows 7, Windows 8/8.1 and Windows 10/11
- Apple macOS 10 & 11 Big Sur
- Google Chrome OS
- No support for Windows RT
Package Contents - USB 3.0 to Gigabit Network Adapter
- Instructions
Additional SKUs
- EAN: 0766623506847
- UPC: 766623506847
Physical Specifications
- Product net weight: 0.05 lbs
- Product gross weight: 0.12 kg
- Dimensions: 2.32 (W) x 0.87 (D) x 0.63 (H) in.
Warning
This product can expose you to chemicals including Cadmium, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.- Driver
- MacOS 10.9 to 10.15 Drivers Installer
Release Date: February 2021
Compatibility:
Please refer to the included installation instructions. » Download - Driver for Windows XP/Vista/7 » Download
- macOS 11.3 (Big Sur)
Release Date: August 2021
Compatibility: AX88179/88772b chipset USB to Ethernet Adapters
Please refer to the included readme file for installation instructions. » Download - Windows 11
Release Date: November 2021
Compatibility: AX88179x, AX88178A, AX88772D chipset USB to Ethernet Adapters » Download - Windows 10
Release Date:May 2022 » Download - v2.2.0 for macOS 12 (Monterey)
Release Date: July 2022
Compatibility: AX88179, AX88178A, AX88772B, AX88772C chipset USB to Ethernet Adapters
Please refer to the included readme file for installation instructions.
Only needed if your system does not automatically install the USB Network Adapter. » Download
