In-wall CL3 High Speed HDMI Cable with Ethernet
In-wall CL3 High Speed HDMI Cable with Ethernet
HEC, ARC, 3D, 4K@60Hz, In-wall Rated, HDMI Male to Male, Shielded, 4.5 m (15 ft.), Black
Highlights
- Supports HDMI Ethernet Channel, Audio Return Channel, 3D Video, 4K@60Hz Display and Deep Color
- CL3 rating for in-wall HDMI installations to safeguard against potential fire risks
- 4K UHD resolution delivering video resolutions two times that of 1080p; up to 1080p resolution in 3D and Deep Color
[ view high resolution images ]
The In-wall CL3 High Speed HDMI Cable - delivering high-definition performance with in-wall rated safety measures
HDMI has become the standard digital connection, delivering the highest-quality audio and video signal over a single cable. This Manhattan CL3 High Speed HDMI Cable is rated for in-wall installation and features an abrasion-resistant design, a sturdy yet flexible PVC jacket and gold-plated contacts. Created to meet both the evolving needs of the HD marketplace and safety standards in fire protection, this cable provides crystal-clear resolution at 4K x 2K (when connected to a compatible source and display), an audio return channel and a bandwidth up to 10.2 Gbps at 340 MHz. It also delivers high-definition video and multichannel, digital audio with increased performance characteristics and greater accuracy. With its fully tested, high-ranked specifications and in-wall fire rating, the Manhattan CL3 High Speed HDMI Cable will future-proof your AV installation.
- Supports HDMI Ethernet Channel, Audio Return Channel, 3D Video, 4K@60Hz Display and Deep Color
- CL3 rating for in-wall HDMI installations to safeguard against potential fire risks
- 4K UHD resolution delivering video resolutions two times that of 1080p; up to 1080p resolution in 3D and Deep Color
- Audio Return Channel (ARC) to allow TV's audio to transmit through your audio system; no need for additional audio cable
- High-speed Ethernet, bi-directional networking up to 100 Mbps
- Bandwidth up to 10.2 Gbps at 340 MHz
- State-of-the-art cable that future-proofs in-home or office HDMI projects
- Compliant with High Speed HDMI with Ethernet specifications
- Double shielded to reduce EMI and other interference sources
- Compatible with any HDMI device, such as Blu-ray, game consoles, stereos, PCs and more
- Lifetime warranty
- Standards and Certifications
- CL3
- UL 20276
- ISO 9001
General - Bandwidth: 10.2 Gbps at 340 MHz
- HEC support
- Meets or exceeds existing HDMI standards
- Length: 4.5 m (15 ft.)
Connectors - Two HDMI 19-pin male
- Gold-plated contacts
- Molded PVC boot
- Built-in strain relief
Cable - 24 AWG cable
- Double shielded
- Current rating: 0.5 A DC
- Withstanding voltage: 300 V DC
- Insulation resistance: 10 MΩ
- Conductive resistance: 5 Ω
- Thermal plastic casing
Package Contents - In-wall CL3 High Speed HDMI Cable with Ethernet Channel
Additional SKUs
- EAN: 0766623354479
- UPC: 766623354479
Physical Specifications
- Product net weight: 0.66 lbs
- Product gross weight: 0.72 kg
- Dimensions: 17.72 (L) x 0.75 (W) x 0.35 (H) [in]
- Datasheet
- Datasheet » Download
